Description
Product Specifications
| Parameter | Value |
|---|---|
| Model | UF1000-PVDF |
| Flow Rate | 1000 LPH |
| Filtration Technology | Ultrafiltration (Hollow Fiber Membranes) |
| Membrane Material | Polyvinylidene Fluoride (PVDF) |
| Filtration Pore Size | 0.01–0.1 microns |
| Operating Pressure | 2–6 bar |
| Inlet/Outlet Size | 3/4 inch |
| Operating Temperature | 5–45°C |
| Power Requirement | None (Gravity or Pump Driven) |
| Dimensions | 1300 mm x 450 mm x 350 mm |
| Weight | Approx. 18 kg |
Features and Benefits
- Advanced PVDF Membranes: Offers exceptional mechanical strength, fouling resistance, and longevity.
- High Flow Rate: Efficiently processes up to 1000 liters of water per hour, ideal for high-demand applications.
- Eco-Friendly Operation: Requires no electricity or chemicals for filtration, making it cost-effective and sustainable.
- Versatile Design: Handles varying water sources, including municipal, well, and surface water.
- Easy Maintenance: Backflushing capability and modular design simplify cleaning and system upkeep.
- Durability: Resistant to chlorine and other oxidants, ensuring long-lasting performance.
Applications
- Residential: Supplies safe and clean water for large households.
- Commercial: Supports water treatment for restaurants, hotels, and small offices.
- Industrial: Effective as a pre-treatment step in large-scale filtration systems.
- Healthcare: Delivers high-purity water for medical and laboratory uses.
System Components
- PVDF UF Membranes: Durable hollow fiber membranes for fine filtration.
Maintenance Guidelines
- Backflush Regularly: Perform system backflushing as per the recommended schedule to avoid fouling.
- Replace Pre-Filters: Change pre-filters every 6–12 months based on water quality.
- Inspect Membranes: Replace PVDF membranes every 2–4 years depending on usage and fouling levels.
Packaging and Storage
- Packaging Details: Supplied with all components securely packed for safe transport.
- Storage Conditions:
- Store in a dry, temperature-controlled area.
- Keep away from direct sunlight and freezing temperatures before installation.
Warranty
- Coverage: 12-month warranty against manufacturing defects.
Safety Information
- Ensure proper pre-treatment for water with high levels of chlorine or turbidity.
- Do not exceed the recommended pressure limits for safe operation.
- Periodically sanitize the system to prevent bacterial growth in the membranes.
