WH250- Aquasolve Automatic Whole-House Multimedia Filtration System with UV Sterilization

Description

Technical Specifications

General Information:

• • Model: WH250
• Application: Whole-house water filtration and sterilization
• Tank Size: 10-inch diameter × 35-inch height
• Tank Material: FRP (Fiber Reinforced Plastic)
• Control Valve: Automatic control valve, JY by Clevalve WH250
• Filter Media: Anthracite, Zeolite, Silica Sand
• Flow Rate:
  • Service Flow Rate: 400 liters per hour (LPH)
  • Backwash Flow Rate: As per control valve specifications

Components:

1. FRP Tank:
   • Size: 10″ × 35″
   • Material: Durable, corrosion-resistant FRP
   • Pressure Rating: Maximum 150 psi (10.3 bar)
   • Temperature Range: 35°F – 120°F (1.7°C – 49°C)
   • Base: 2.5″–8 NPSM threaded opening
2. Filter Media:
   • Anthracite:
     • Function: Removes turbidity, suspended solids, and organic contaminants
     • Layer Position: Top layer
   • Zeolite:
     • Function: Removes ammonia, heavy metals, and reduces odors
     • Layer Position: Middle layer
   • Silica Sand:
     • Function: Fine filtration of sediments and particulates
     • Layer Position: Bottom layer
   • Media Volume: Optimized layering for maximum filtration efficiency
3. 2-in-1 Micron Filter:
   • Configuration: Dual-stage filtration in a single housing
   • First Stage: 5-micron sediment filter to remove larger particulates
   • Second Stage: 1-micron filter for finer particulates and some microbial cysts
   • Filter Material: Polypropylene or pleated cellulose
   • Housing Material: NSF-certified thermoplastic
   • Connections: 3/4″ or 1″ NPT/BSP inlet and outlet
4. 16W UV Sterilizer:
   • Lamp Power: 16 Watts
   • Flow Rate Capacity: Up to 400 LPH
   • Chamber Material: Stainless Steel 304
   • Lamp Life: 9,000 hours
   • UV Dose: >30,000 μW-sec/cm²
   • Power Supply: 110V/60Hz or 220V/50Hz (specify upon ordering)
   • Features: Visual lamp indicator, audible alarm for lamp failure
5. Automatic Control Valve:
   • Brand: JY by Clevalve
   • Model: WH250
   • Type: Fully automatic multi-port valve
   • Material: High-strength thermoplastic
   • Connections: 1″ NPT/BSP inlet and outlet
   • Operation: Programmable settings for service, backwash, and rinse cycles
   • Features: Digital display, user-friendly interface, battery backup
   • Power Supply: 110V/60Hz or 220V/50Hz (specify upon ordering)

Operating Conditions:

• Feed Water Temperature: 35°F – 100°F (1.7°C – 38°C)
• Feed Water pH Range: 6.5 – 9.5
• Maximum Operating Pressure: 100 psi (6.9 bar)
• Maximum Iron Content: Less than 0.3 ppm
• Maximum Turbidity: Less than 5 NTU
• Electrical Requirements:
  • Control Valve: 110V/60Hz or 220V/50Hz, power consumption approx. 5W
  • UV System: 110V/60Hz or 220V/50Hz, power consumption approx. 20W

Connections:

• Inlet/Outlet Ports: 1″
• Drain Connection: 1/2″ or 3/4″ for backwash line
• Electrical Connection: Standard power outlet for control valve and UV system

Physical Dimensions:

• Tank Diameter: 10 inches (254 mm)
• Tank Height (without control valve): 35 inches (889 mm)
• Overall Height (with control valve and UV unit): Approximately 45 inches (1143 mm)
• Footprint: Compact design suitable for limited spaces
• Weight (Dry): Approximately 60 pounds (27 kg)
• Weight (Wet): Approximately 200 pounds (91 kg)

Features & Benefits

• Advanced Filtration:
  • Multimedia Layers: The combination of anthracite, zeolite, and silica sand effectively removes a wide range of contaminants, including sediments, turbidity, heavy metals, and organic compounds.
• Enhanced Safety:
  • UV Sterilization: The 16W UV lamp provides an additional layer of protection by inactivating bacteria, viruses, and other microorganisms without the use of chemicals.
• Automatic Operation:
  • JY by Clevalve WH250 Control Valve: Automates the filtration process with programmable settings for service, backwash, and rinse cycles, ensuring optimal performance with minimal manual intervention.
• Consistent Flow Rate:
  • 400 LPH Capacity: Provides a steady flow of clean water suitable for residential use, ensuring all household needs are met.
• User-Friendly Interface:
  • Digital Display and Controls: Easy programming and monitoring of system status and operation cycles.
• Durable Construction:
  • High-Quality Materials: FRP tank and stainless steel UV chamber designed for longevity and resistance to corrosion.
• Energy Efficient:
  • Low Power Consumption: Both the control valve and UV system are designed to operate efficiently, reducing energy costs.
• Compact Design:
  • Space-Saving Footprint: Ideal for installations where space is limited.
• Low Maintenance:
  • Automated Backwashing: The automatic control valve schedules regular backwashing to maintain filter efficiency without manual intervention.

Applications

• Residential Use: Ideal for whole-house water treatment, providing clean water to all faucets and appliances.
• Light Commercial: Suitable for offices, small businesses, and clinics requiring improved water quality.
• Well Water Treatment: Addresses common issues like turbidity, sediment, and microbial contamination in groundwater.
• Municipal Water Treatment: Enhances the quality of city water by removing residual contaminants.

Scope of Supply

• Main Unit: 10″ × 35″ FRP tank pre-filled with anthracite, zeolite, and silica sand layers
• 2-in-1 Micron Filter Housing: Complete with 5-micron and 1-micron filter cartridges
• 16W UV Sterilizer: Includes UV chamber, lamp, quartz sleeve, and power supply
• Automatic Control Valve: JY by Clevalve WH250, pre-installed and programmed
• Distributor Assembly: Internal riser tube and bottom distributor included
• Installation Kit: Necessary fittings and hardware
• User Manual: Comprehensive installation and operation instructions

Optional Accessories

• Sediment Pre-Filter: Additional protection for heavily sedimented water sources
• Activated Carbon Filter: For removal of chlorine, chloramines, and organic compounds
• Pressure Regulator: Protects the system from pressure surges
• Flow Meter: Monitors water usage and helps schedule maintenance
• Spare Parts Kit: Includes extra filter cartridges, UV lamp, and quartz sleeve

Installation & Maintenance

• Installation:
  • Should be performed by a qualified technician.
  • Requires connection to the main water supply, drain line for backwashing, and electrical outlets for the control valve and UV system.
  • Placement should allow easy access for operation and maintenance.
• Maintenance:
  • Media Replacement: Filter media typically lasts 3–5 years; replace as needed based on water quality and usage.
  • Micron Filter Replacement: Replace filter cartridges every 3–6 months or as needed.
  • UV Lamp Replacement: Replace the UV lamp annually or after 9,000 hours of operation.
  • Backwashing: Automatic backwash cycles are scheduled by the control valve to flush out trapped contaminants.
  • System Checks: Regularly inspect the control valve, UV system, and connections for leaks or wear.

Warranty & Support

• Warranty: 1-year limited warranty covering manufacturing defects on all system components.
• Technical Support: Available via phone or email during business hours for troubleshooting and inquiries.
• Replacement Parts: Easily obtainable for media, filters, UV components, and other parts to ensure longevity.
• Service Plans: Optional maintenance contracts available for regular servicing and priority support.

Ordering Information

• Product Code: WH250
• Availability: Typically in stock; please contact us for current lead times.
• Customization: Specify electrical requirements (110V/60Hz or 220V/50Hz) and any optional accessories when placing your order.
